Video inputs and outputs
8 inputs (AHD / TurboHD / TVI / CVBS) + 1 inputs (IP) ; Only IP - 9 inputs ; HDMI x 1, VGA x 1
Audio inputs and outputs
1 input (RCA) / 1 output (RCA) + IP cameras, 2-way audio
Video compression
H.264
Data bandwidth IN / OUT
4Mbps (6 IP channels), 36Mbps (2 IP channels) / 18 Mbps
Max decoding
AHD/TVI/TurboHD/CVI: 2MP Lite @ 12/15ps per channel ; IP: 2MP @ 25/30fps per channel
Alarm inputs and relay outputs
Input and output count depends on IP cameras
Storage
1 x SATA HDD up to 8TB (Not included)
Power supply
DC12V / 2A
Dimensions
255(W) x 43(H) x 220(D) mm
